SAGE has a wide variety of state of the art surveying instruments including 3D terrestrial laser scanner, GNSS RTK systems, robotic total stations, digital levels and RPAS/UAS/Drones.
Scheduled teaching classes have the highest priority to book and use the instruments.
SAGE Instruments can be booked on CVEN Intranet.
Robotic Total Stations
- Leica TS60 R1000
- Topcon GT-603
- Leica TCRP1203+ R400, RX1250T
- Trimble RTS S6 + TSC2
Digital Total Stations
- Sokkia SET530RK3
- Operators manual
- Sokkia USB-to-Serial cable (black) driver (change .txt to .zip to unzip. also check readme.txt before installation)
- Survey data download and upload with Magnet Office 5 and Windows 10 quick guide (PDF).
- FOIF RTS102
- User manual (PDF)
- Quick start guide (PDF)
- Data transfer app (change .txt to .zip and unzip)
Photogrammetry and Remote Sensing Devices
Digital Camera
- DSLR cameras for close range photogrammetry
Planar Stereoscopic photogrammetry workstation
- Planar SD1710 3D stereo photogrammetry workstations
Other devices
- iPad13 Pro with lidar capability
- Leica BLK3D
Digital Levels
- Trimble DiNi22 (user guide)
- Leica Sprinter 50 (user guide)
- Topcon DL101C
- Sokkia SDL30
GNSS Receivers
- Leica GNSS Receivers (CS15/GS15) (equipment list)
- Leica GNSS Receivers (GX1230/RX1210T/AX1202GG) (user guide)
- Trimble R1 (photo, user guide)
- Garmin handheld e-Trex10 (user guide)
UAS/RPAS/Drones
- Matrice 300 RTK + MicaSense Altum-PT multispectral camera payload
- Matrice 200 V2 + Teledyne FLIR VUE TZ20-R thermal camera payload
- DJI Matrice 600 Pro + Phoenix Lidar SCOUT-16 payload
- DJI Phantom 4 Pro with a RGB camera
- Sensefly SwingletCAM + RGB camera (decommissioned)
- Sensefly eBee-RTK + RGB & NIR cameras (decommissioned)
- DJI Phantom 3 Pro (decommissioned)
- 3DR SOLO + Sony QX1 camera (decommissioned)
Lidar / Laser Scanners
Terrestrial Laser Scanners
- Leica ScanStation C5 (equipment list)
- GeoSLAM ZEB Revo handheld (user manual)
Other devices
- Electronic Theodolites
- Optical Theodolites
- Dumpy Levels
- Ground Penetrating Radar (GPR)
- Invar Staves
- Leica Prisms
- Mini-prisms with poles
- Leica Multi-prisms (GPH11)
- Leica tri-prisms (photo)
- Leica Distos
- 360-deg prisms
- 360-deg mini prisms
- Adjustment station for prism poles - Control and Adjusting Station for Prism Poles and Antenna Poles (user guide)
- Adjusting device for optical plummets and circular bubbles (manual)
- Adjustment cylinder for optical plummets (photo, manual)
